Outdoor Self-Ordering Kiosk with Solar Charging for Remote Locations
Key Specifications/ Special Features:
Outdoor Self-Ordering Kiosk with Solar Charging for Remote Locations
The Outdoor Self-Ordering Kiosk is a robust and innovative solution designed to meet the unique challenges of remote and off-grid locations. Featuring solar charging capabilities, this kiosk operates efficiently without relying on traditional power sources, making it ideal for parks, campgrounds, rural businesses, and other remote areas. Its weatherproof enclosure ensures reliable performance in outdoor environments, protecting the kiosk from rain, dust, and extreme temperatures, while the high-brightness display guarantees clear visibility even in direct sunlight.
This kiosk is equipped with a responsive touch interface that provides a seamless and intuitive user experience, allowing customers to browse menus, place orders, and complete transactions with ease. The wireless connectivity enables real-time updates and remote management through cloud-based software, ensuring that the kiosk remains up-to-date and operational even in the most isolated locations. With its eco-friendly design and energy-efficient operation, this kiosk not only reduces environmental impact but also lowers operational costs, making it a sustainable choice for businesses and organizations.
Whether deployed in a national park, a rural market, or a remote campground, the 32 Inch Outdoor Self-Ordering Kiosk delivers a reliable, efficient, and environmentally friendly solution that enhances customer convenience and satisfaction.
Key Features:
- Outdoor touchscreen display: Designed for clear visibility and durability in outdoor environments.
- Solar charging capabilities: Enables off-grid operation, reducing reliance on traditional power sources.
- Weatherproof enclosure: Protects the kiosk from rain, dust, and extreme temperatures.
- High-brightness display: Ensures clear visibility even in direct sunlight.
- Responsive touch interface: Provides a seamless and intuitive user experience.
- Wireless connectivity: Supports cloud-based updates and remote management for real-time operation.
- Eco-friendly design: Reduces environmental impact with solar power and energy-efficient operation.
- Energy-efficient operation: Minimizes power consumption while maintaining high performance.
| LCD Panel Parameters | Screen Size | 15.8 inch | |
| Display area | 344.16(H) X 193.59(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 450 X 310 X 110mm | ||
| The Gross weight of Unit Package | 50kg | ||
| Weight | 50 kg |
|---|---|
| Dimensions | 87,4 × 14,2 × 58,7 cm |
