Large-Scale Self-Ordering Kiosk with Split-Screen Functionality for High-Traffic Areas
Key Specifications/ Special Features:
Large-Scale Self-Ordering Kiosk with Split-Screen Functionality for High-Traffic Areas
The Large-Scale Self-Ordering Kiosk is a powerhouse solution designed to meet the demands of high-traffic environments such as stadiums, convention centers, large retail stores, and busy food courts. Featuring split-screen functionality, this kiosk allows multiple customers to place orders simultaneously, significantly reducing wait times and improving operational efficiency. Its large touchscreen display ensures clear visibility in any lighting condition, making it perfect for bustling venues where quick and seamless service is essential.

Built with a rugged, anti-vandal design, this kiosk is engineered to withstand heavy usage and harsh conditions, ensuring long-lasting performance even in the most demanding environments. The high-brightness display guarantees vibrant visuals, while the advanced payment options—including cashless and card payments—enable quick and secure transactions. The kiosk’s customizable software allows businesses to tailor the interface to their branding and promotional needs, creating a cohesive and engaging customer experience.

With easy installation and maintenance, this kiosk is designed to minimize downtime and operational costs. Its energy-efficient operation reduces power consumption, making it a sustainable choice for businesses looking to balance performance with environmental responsibility. Whether you’re managing a packed stadium, a bustling convention center, or a high-volume retail store, this kiosk ensures a seamless and efficient ordering experience for both customers and businesses.

Key Features:
- Large-scale touchscreen display: Provides clear visibility and an immersive user experience.
- Split-screen functionality: Allows multiple customers to place orders simultaneously, reducing wait times.
- High-brightness display: Ensures vibrant visuals in any lighting condition.
- Rugged, anti-vandal design: Built to withstand heavy usage and harsh environments.
- Advanced payment options: Supports cashless and card payments for quick and secure transactions.
- Customizable software: Enables branding and promotional customization for a cohesive experience.
- Easy installation and maintenance: Minimizes downtime and operational costs.
- Energy-efficient operation: Reduces power consumption while maintaining high performance.

Applications:
This kiosk is perfect for stadiums, where it can handle high volumes of customers ordering food, beverages, or merchandise during events. It’s also ideal for convention centers, streamlining registration, ticketing, and concession orders. In large retail stores, the kiosk can enhance the shopping experience by facilitating quick checkouts or providing product information. Additionally, it’s a great fit for busy food courts, where its split-screen functionality ensures fast and efficient service during peak hours.

Why Choose This Kiosk?
The Large-Scale Self-Ordering Kiosk is more than just a self-service tool—it’s a strategic asset for businesses operating in high-traffic environments. By combining split-screen functionality, a rugged design, and advanced payment options, this kiosk ensures that customers are served quickly and efficiently, even during the busiest times. Its customizable software and energy-efficient operation make it a versatile and sustainable solution for businesses looking to enhance customer satisfaction and streamline operations.
LCD Panel Parameters | Screen Size | 21.5 inch | |
Display area | 476.5(H) X 268(V)mm | ||
Aspect Ratio | 16 : 9 | ||
LCD Type | a-Si TFT-LCD | ||
Max Resolution | 1920 X 1080 | ||
Display color | 16.7M , 72% NTSC | ||
Brightness | 350 cd/㎡ | ||
Contrast Ratio | 3000 :1 | ||
Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
Response Time | 20ms | ||
LCD Panel Life(hrs) | 60,000(hrs) | ||
Field Frequency | 60Hz | ||
PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
Touch points | 10 points | ||
Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
Anti-microbial protection and Shatterproof Protection | |||
Optically bonded 3mm glass for low parallax | |||
The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
Response speed | < 6ms | ||
Accuracy of touch | More than 90% of the touch area ±2mm | ||
Touch ways | Fingers, touch pen | ||
Output format | The coordinate output | ||
Clicks time | Unlimited | ||
The smallest touch size | 5mm | ||
Long resistance | Yes available | ||
Touch Interfaces | USB | ||
Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
Mini PC Parameters (Fan-less Industrial PC) | CPU | Celeron J1900 | |
RAM | 8GB | ||
SSD | 64GB | ||
WIFI | 150Mbps 802.11n wifi integate | ||
Network port | RJ45, 10M/100M Adaptive Ethernet | ||
Interface | 2 * RJ45 GB Ethernet | ||
2 * RS232 Serial Port | |||
operating system | Win10 or win11 optional | ||
Onboard interface | HDMI input | 1 | |
VGA input | 1 | ||
DVI input | 1 | ||
USB Type B or Any USB Type optional | 1 | ||
Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
Receipt Printer | 80mm Thermal printer with cutter | ||
Power | Power supply | AC 100V~240V, 50/60Hz | |
The Max power loss | ≤ 45w | ||
Standby power loss | < 1W | ||
Features | Operating temperature | 0℃ ~ 50℃ | |
Storage temperature | below10℃ ~ +60℃ | ||
Accessories | The length of Power Cable | 1.5m | |
The length of HDMI Cable | 2m | ||
The length of USB-A to USB-B Cable | 1.5m | ||
Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
Package size | Machine body size | Customized | |
Net weight | Customized | ||
Unit Package size | 585 X 380 X 110mm | ||
The Gross weight of Unit Package | 50kg |
Weight | 50 kg |
---|---|
Dimensions | 87,4 × 14,2 × 58,7 cm |
