Curved Self-Ordering Kiosk with Immersive Display for Entertainment Venues
Key Specifications/ Special Features:
Curved Self-Ordering Kiosk with Immersive Display for Entertainment Venues
The Curved Self-Ordering Kiosk is a game-changing solution designed to captivate customers and elevate their ordering experience in entertainment venues. Featuring an immersive curved display, this kiosk combines stunning visuals with advanced functionality, making it the perfect addition to cinemas, arcades, theme parks, and entertainment complexes. The large, curved screen not only draws attention but also provides a wide viewing angle, ensuring that customers can easily interact with the kiosk even in high-traffic areas.
This kiosk is built to handle the demands of busy entertainment environments, offering NFC and contactless payment support for quick, secure, and hassle-free transactions. Whether customers are purchasing movie tickets, ordering snacks, or redeeming game credits, the process is seamless and efficient. The high-brightness display ensures vibrant visuals, even in brightly lit venues, while the durable construction guarantees long-lasting performance, even under heavy usage.
The customizable software allows businesses to tailor the kiosk to their specific entertainment applications, whether it’s displaying movie schedules, promoting special offers, or showcasing interactive content. Additionally, the easy-to-clean surface ensures hygiene maintenance, making it a practical choice for environments where cleanliness is a priority.
Key Features:
- Curved touchscreen display: Delivers an immersive and engaging customer experience.
- Immersive design: Captivates customers and enhances interaction with its curved screen.
- Wide viewing angle: Ensures easy access and visibility in high-traffic areas.
- NFC and contactless payment support: Enables quick, secure, and convenient transactions.
- High-brightness display: Provides vibrant visuals, even in brightly lit environments.
- Durable construction: Built to withstand heavy usage in busy entertainment venues.
- Customizable software: Tailored for entertainment applications, such as ticket sales and promotions.
- Easy-to-clean surface: Simplifies hygiene maintenance for a clean and professional appearance.
It is perfect for cinemas, where it can streamline ticket purchases, concession orders, and loyalty program integrations. It’s also ideal for arcades, allowing customers to easily purchase game credits or redeem rewards. In theme parks, the kiosk can enhance the guest experience by facilitating ticket sales, food orders, and interactive wayfinding. Additionally, it’s a great fit for entertainment complexes, sports arenas, and concert venues, where its immersive design and advanced functionality can handle high customer volumes while delivering a memorable experience.
Why Choose This Kiosk?
The Curved Self-Ordering Kiosk is more than just a self-service tool—it’s an experience enhancer. By combining an immersive curved display with advanced features like NFC payments and customizable software, this kiosk ensures that customers are not only served efficiently but also engaged and delighted. Its durable construction and easy-to-clean surface make it a practical choice for high-traffic entertainment venues, while its sleek design adds a modern touch to any environment.
| LCD Panel Parameters | Screen Size | 27 inch | |
| Display area | 597.9(H) X 336.3(V)mm | ||
| Aspect Ratio | 16 : 9 | ||
| LCD Type | a-Si TFT-LCD | ||
| Max Resolution | 1920 X 1080 | ||
| Display color | 16.7M , 72% NTSC | ||
| Brightness | 350 cd/㎡ | ||
| Contrast Ratio | 3000 :1 | ||
| Viewing angle(up/down/left/right) | 89/89/89/89 (Typ.)(CR≥10) | ||
| Response Time | 20ms | ||
| LCD Panel Life(hrs) | 60,000(hrs) | ||
| Field Frequency | 60Hz | ||
| PCAP Touchscreen Panel Parameters | Touch style | Projected Capacitive Touch screen | |
| Touch points | 10 points | ||
| Cover Glass | Physical toughened Morse magnitude 7 explosion-proof | ||
| Anti-microbial protection and Shatterproof Protection | |||
| Optically bonded 3mm glass for low parallax | |||
| The glass transmittance | >88%(Higher transmittance depends on the glass surface treatment technology, eg AR/AG) >88% | ||
| Response speed | < 6ms | ||
| Accuracy of touch | More than 90% of the touch area ±2mm | ||
| Touch ways | Fingers, touch pen | ||
| Output format | The coordinate output | ||
| Clicks time | Unlimited | ||
| The smallest touch size | 5mm | ||
| Long resistance | Yes available | ||
| Touch Interfaces | USB | ||
| Operating temperature & Humidity | below10℃ ~ +50℃, ≤ 85%RH | ||
| Storage temperature & Humidity | below20℃ ~ +60℃, ≤ 90%RH | ||
| Mini PC Parameters (Fan-less Industrial PC) | CPU | Celeron J1900 | |
| RAM | 8GB | ||
| SSD | 64GB | ||
| WIFI | 150Mbps 802.11n wifi integate | ||
| Network port | RJ45, 10M/100M Adaptive Ethernet | ||
| Interface | 2 * RJ45 GB Ethernet | ||
| 2 * RS232 Serial Port | |||
| operating system | Win10 or win11 optional | ||
| Onboard interface | HDMI input | 1 | |
| VGA input | 1 | ||
| DVI input | 1 | ||
| USB Type B or Any USB Type optional | 1 | ||
| Parts(Built-in) | QR/Barcode Reader | Can recognize 1D barcode and 2D barcode | |
| Receipt Printer | 80mm Thermal printer with cutter | ||
| Power | Power supply | AC 100V~240V, 50/60Hz | |
| The Max power loss | ≤ 45w | ||
| Standby power loss | < 1W | ||
| Features | Operating temperature | 0℃ ~ 50℃ | |
| Storage temperature | below10℃ ~ +60℃ | ||
| Accessories | The length of Power Cable | 1.5m | |
| The length of HDMI Cable | 2m | ||
| The length of USB-A to USB-B Cable | 1.5m | ||
| Versatile Mounting Solution | Wall Mounted | with walll mount bracket | |
| Stand Holder(Optional) | Movable, can be with wheels on the base, height is adjustable | ||
| Package size | Machine body size | Customized | |
| Net weight | Customized | ||
| Unit Package size | 720 X 460 X 120mm | ||
| The Gross weight of Unit Package | 50kg | ||
| Weight | 50 kg |
|---|---|
| Dimensions | 87,4 × 14,2 × 58,7 cm |
